Insulation material......................................................PPE
Rated current..............................................................30A
Rated voltage.............................................................1000V(TUV)&600V(UL)
Test voltage................................................................6kv(50Hz,lmin
Typical contact resistance........................................... 5m
Contact material.........................................................Copper,Tin plated
Degree of protection...................................................IP2X/IP67
Safety degree.............................................................II
Flame class.................................................................UL94-V0
Material RTI................................................................110C
Withdrawal force........................................................ 50N
Insertion force............................................................ 50N
Ambient temperature range.......................................-40도C until+85도C
Pin dimensions...........................................................3.0
Suitable cable cross section.......................................2.5/4.0/6.0mm2
